Real Instruments HTC PDF LOG Advanced Humidity and Temperature Data Logger with High-Precision Sensors, Wide Measurement Range, Large Data Storage Capacity, USB Connectivity, Automatic PDF Report Generation, LCD Display, and Long Battery Life

HTC PDF LOG Humidity & Temperature Data Logger Specifications:

Temperature Measurement

• Range: -30°C to +70°C (-22°F to +158°F)
• Accuracy: ±0.5°C (-20°C to +40°C); ±1.0°C (outside -20°C to +40°C)
• Resolution: 0.1°C

Humidity Measurement

• Range: 0% RH to 100% RH
• Accuracy: ±3% RH (20% to 80% RH); ±5% RH (outside 20% to 80% RH)
• Resolution: 0.1% RH

Memory Capacity

• Stores up to 32,000 data points (16,000 for temperature and 16,000 for humidity)

Sampling Interval

• User-configurable from 10 seconds to 24 hours

Alarm Settings

• Programmable high/low limits for temperature and humidity
• Visual alarm indicators

Power Supply

• Replaceable lithium battery (CR2032)
• Battery life: Up to 6 months (depending on usage)

Connectivity

• USB interface for direct connection to a computer
• No additional cables or software required

Report Generation

• Automatic PDF report generation upon connection to a computer
• No software installation needed

Display

• Large LCD screen displaying current temperature, humidity, logging status, and battery level

Operating Conditions

• Temperature: -30°C to +70°C (-22°F to +158°F)
• Humidity: 0% RH to 85% RH (non-condensing)

Dimensions

• 100mm x 40mm x 20mm (3.94 x 1.57 x 0.79 inches)

Weight

• Approximately 80 grams (2.82 oz)

Certifications

• CE, RoHS compliant

HTC PDF LOG Humidity & Temperature Data Logger Description:

The HTC PDF LOG Humidity & Temperature Data Logger is a compact and efficient solution for real-time monitoring and recording of temperature and humidity levels. With a wide temperature range of -30°C to +70°C and full-spectrum humidity monitoring, it is ideal for cold chain logistics, medical storage, industrial environments, and food safety monitoring.

Equipped with a large LCD screen, the logger provides real-time display of current temperature, humidity, logging status, and battery level. The memory capacity of 32,000 readings ensures comprehensive data storage for extended periods, and customizable sampling intervals offer flexible monitoring options tailored to various applications.

The device features USB connectivity, allowing users to directly plug it into a computer without the need for additional cables or software. Automatic PDF report generation simplifies data analysis and compliance with industry standards.

Powered by a replaceable lithium battery, the HTC PDF LOG provides up to 6 months of reliable operation under typical usage conditions. Its durable and portable design ensures easy deployment in demanding environments.

Whether for regulatory compliance or quality assurance, the HTC PDF LOG Humidity & Temperature Data Logger is an accurate, user-friendly, and cost-effective tool for environmental monitoring.
