Real Instruments HTC High Voltage Detector HP-500 Non-Contact Voltage Tester for AC Voltages Ranging from 220V To 500kV with LED Indicators, Audible Alarm, Adjustable Sensitivity, IP54 Dust and Water Resistance, and Long Battery Life for Electrical Safety

The HTC High Voltage Detector HP-500 is a safety tool used to detect high voltage in electrical systems. It is commonly used by electrical professionals, engineers, and safety personnel to ensure that electrical equipment and systems are properly de-energized before maintenance or service work is conducted. Below are the specifications and a description of the product.

Specifications:

• Voltage Detection Range: 70V AC to 500kV AC
• Detection Type: Non-contact voltage detection
• Sensitivity: Adjustable sensitivity settings to detect varying voltage levels
• Indicator: LED indicators and audible alarm
  • Green LED: Safe voltage range
  • Red LED: High voltage presence detected
  • Audible Alarm: Sounds when high voltage is detected
• Operating Temperature Range: -10°C to 50°C (14°F to 122°F)
• Power Supply: Powered by 2 x AA batteries
• Battery Life: Approximately 300 hours of continuous operation (depending on usage)
• Size: Compact and portable
• Weight: Approximately 0.15 kg (150 grams)
• Certifications: CE, UL, and other industry-specific standards for safety and quality
• Water and Dust Resistance: IP54 rated for water and dust protection
• Display: LED indicators for voltage level and operational status
• Safety Features: Over-voltage warning, low battery indication, and auto power-off to conserve battery life

Description:

The HTC High Voltage Detector HP-500 is a non-contact, handheld device designed for safely detecting the presence of high voltage in electrical systems. It is ideal for maintenance personnel, electricians, and anyone working with high-voltage electrical equipment, providing a fast and reliable method for determining if a system is energized.

The HP-500 can detect AC voltages ranging from as low as 70V AC up to a massive 500kV AC, making it suitable for a wide range of applications, from household electrical systems to industrial power grids and substations. The device uses non-contact detection technology, meaning it can detect high voltage without direct contact with the electrical conductors, minimizing the risk of electric shock.

When voltage is detected, the LED indicators show a green light for safe conditions and a red light for high-voltage presence. Additionally, an audible alarm activates to provide an additional safety measure. This ensures that the user is immediately aware of any potentially dangerous electrical presence.

The HP-500 is designed to be lightweight and portable, with a compact form factor that makes it easy to carry and operate in tight or confined spaces. It operates on two AA batteries, offering up to 300 hours of continuous use. Its IP54 rating ensures that it is protected from dust and water splashes, making it suitable for use in various weather conditions and challenging work environments.

This voltage detector is built to meet the highest safety standards, including CE and UL certifications, ensuring that it delivers accurate and reliable performance while maintaining strict safety protocols. It is an essential tool for electrical safety, helping prevent accidents and injuries related to electrical hazards.

The HTC High Voltage Detector HP-500 is a valuable instrument for anyone working with high-voltage systems, providing clear, real-time feedback about the presence of voltage and ensuring that electrical systems are safe to work on.
