Real Instruments HTC HD-303 Mini Thermo Hygrometer with Dew Point and Wet Bulb Temperature Measurement, Large Backlit LCD, Max/Min Function, and Data Hold for Industrial, HVAC, and Environmental Applications
Real Instruments HTC HD-303 Mini Thermo Hygrometer with Dew Point and Wet Bulb Temperature Measurement, Large Backlit LCD, Max/Min Function, and Data Hold for Industrial, HVAC, and Environmental Applications
The HTC HD-303 Mini Hygrometer is a compact and versatile instrument designed for measuring ambient temperature and humidity. Its user-friendly features make it suitable for various applications, including HVAC maintenance, environmental monitoring, and industrial processes.
Key Specifications:
-
Humidity Measurement:
- Range: 0.0% to 99.9% Relative Humidity (RH)
- Resolution: 0.1% RH
-
Accuracy:
- 20% to 80% RH: ±3.0% RH
- Other ranges: ±4.0% RH
-
Temperature Measurement:
- Range: -20.0°C to 60.0°C (-4.0°F to 140.0°F)
- Resolution: 0.1°C/°F
-
Accuracy:
- 0.0°C to 45.0°C: ±1.5°C
- Other ranges: ±1.5°C
-
Wet Bulb Temperature Measurement:
- Range: -20.0°C to 60.0°C (-4.0°F to 140.0°F)
- Resolution: 0.1°C/°F
-
Accuracy:
- 0.0°C to 45.0°C: ±1.0°C
- Other ranges: ±1.5°C
-
Dew Point Temperature Measurement:
- Range: -50.0°C to 60.0°C (-58.0°F to 140.0°F)
- Resolution: 0.1°C/°F
-
Accuracy:
- 0.0°C to 45.0°C: ±1.0°C
- Other ranges: ±1.5°C
-
Sampling Rate: 2.5 samples per second
-
Display: Large backlit LCD for clear readability
-
Power Supply: Three AAA 1.5V batteries
-
Dimensions: 155 mm (H) x 50 mm (W) x 28 mm (D)
-
Weight: Approximately 150 grams
Features:
-
Data Hold Function: Allows users to freeze the current reading on the display for easy recording.
-
Max/Min Function: Enables tracking of maximum and minimum readings over time.
-
Backlight: Illuminated display for visibility in low-light conditions.
-
Dew Point Measurement: Provides dew point temperature readings, essential for assessing condensation risk.
-
Auto Power Off: Conserves battery life by automatically shutting down after 30 minutes of inactivity.
Applications:
-
HVAC Systems: Monitoring and adjusting environmental conditions to ensure optimal system performance.
-
Environmental Monitoring: Assessing indoor air quality and maintaining comfort levels in various settings.
-
Industrial Processes: Ensuring appropriate temperature and humidity levels critical to manufacturing and storage.
-
Agricultural Settings: Monitoring conditions in greenhouses and storage facilities to preserve crop quality.
Standard Accessories:
-
User Manual
-
Soft Carrying Case
-
Batteries
