True Sense Technologies

Real Instruments HTC PM-6130 Digital Manometer - Advanced Precision Instrument for Multi-Range Pressure Measurement up to 30 PSI with Backlit LCD Display, Multiple Pressure Units, and Enhanced Portability

Real Instruments HTC PM-6130 Digital Manometer - Advanced Precision Instrument for Multi-Range Pressure Measurement up to 30 PSI with Backlit LCD Display, Multiple Pressure Units, and Enhanced Portability

Regular price Rs. 4,123.00
Regular price Sale price Rs. 4,123.00
Sale Sold out
Taxes included. Shipping calculated at checkout.

The HTC PM-6130 Digital Manometer is a versatile instrument designed for precise pressure measurements across various units. It offers 11 selectable pressure ranges, including psi, inches of water (inH₂O), and millibar (mbar), among others. The device features a backlit LCD display for clear readings in low-light conditions and includes an auto power-off (APO) function to conserve battery life. It operates on a 9V (6F22) battery and comes with standard accessories such as a soft carrying case, soft tubes, a manual, and metal gas mouths. The manometer's dimensions are 140mm (H) x 20mm (W) x 50mm (D).



Specifications:

  • Pressure Ranges and Resolutions:

    • inH₂O: ±830 with 1 resolution
    • psi: ±30.00 with 0.01 resolution
    • mbar: ±2068 with 1 resolution
    • kPa: ±206.8 with 0.1 resolution
    • inHg: ±61.08 with 0.1 resolution
    • mmHg: ±1551 with 1 resolution
    • oz/in²: ±480.0 with 0.1 resolution
    • ftH₂O: ±69.2 with 0.01 resolution
    • cmH₂O: ±2109 with 1 resolution
    • kg/cm²: ±2.109 with 0.001 resolution
    • bar: ±5.138 with 0.001 resolution
  • Accuracy: ±0.3% of Full Scale (FS)

  • Linearity/Hysteresis: ±0.1% FS

  • Repeatability: ±0.25% FS

  • Pressure Connector: 1/8" (3.18mm) quick connector

  • Over Range Indication: ERR1 or ERR2

  • Operating Temperature: 0°C to 40°C

  • Storage Temperature: -10°C to 60°C

  • Power Supply: 9V (6F22) battery
